The YHF welding cable figures copper conductor with ethylene propylene rubber (EPR) insulation. It is referred to CU/EPR. Mainly follows the standard IEC 60245 and BS EN

1. Voltage & Weather Resistance

• Utilizes pure natural rubber insulation for balanced electrical conductivity and safety performance.
• Engineered to withstand high-voltage stress and extreme weather fluctuations.

2. Flexibility & Bend Performance

• Superior flexibility, ideal for high-frequency movement/twisting in welding operations.

3. Abrasion & Mechanical Resilience

• Elastomeric outer sheath provides:
  ✓ Tear resistance (≥15 N/mm tensile strength)
  ✓ Enhanced abrasion resistance (tested under 10,000+ friction cycles)
  ✓ Crush resistance for harsh worksites.

4. Chemical & Environmental Durability

• Operates reliably in hazardous conditions:
  ✓ High-temperature exposure (up to 90°C)
  ✓ Immersion in boiling water, mud, oils, and acid/alkali solutions (pH 2-12).
• Certified oil/solvent resistance (compatible with ISO 1817 standards).

5. Compact & Lightweight Design

• Reduced diameter-to-weight ratio simplifies handling in confined spaces (e.g., shipyards, construction rigs).

Description Of YHF welding cable

• Rated Temperature:  90℃
• Rated Voltage:  300/500V, 450/750V
• Reference Standard:  IEC 60245/BS EN50525-2-81
• Conductor: Shaped and circular stranded copper conductors
• Insulated: ethylene propylene rubber (EPR)
